Application
The mechanical seal has a simple structure. The large line diameter and large pitch make the spring insensitive to corrosion and can prevent clogging and sticking of impurities, ensuring reliable and tight fitting of the seal faces in harsh environments and having a wide range of applications.

Design Features
·Single and unbalanced seal
·Single spring, no rotation requirement
·Comply with DIN24960 and GB6556 standards
·Seal faces can be paired with various materials

Performance Parameters
·Temperature: -40℃ to 220℃
·Pressure: Maximum 1Mpa (not suitable for working in negative pressure environment and vacuum state)
·Speed: Maximum 25m/s (5000rpm)
